Unitek 9500 Series

Universal Testing Machine
Features
• Completely PC Controlled.
• Electronic outside PC cabinet. only one RS232C Serial on     PC is    required free for interface. It is    having    advantage    of Ease of    Commissioning, Maintenance,    Calibration,    Trouble shooting etc.   No any specification     requirements    of PC cabinet size, nor any ISA    or PCI     free slot required.    Reduced PC related problems,     failures   etc.
• Auto communication port detection on PC.
• Any latest PC with windows 98/XP installed can be used.
All display / control through PC only

Window Based Software Features

• Graph Comparison, point tracing on Graph, Selection result printout.
• Graph Zooming, Scaling, Different units selection for Load & Displacement.
• Test certificate & Single graph Printout. Any printer is suitable.
• Statistical evaluation software, includes Water Fall dig. Mean deviation, frequency distrubution, Screw dig., Histogram. also     calculatates max Value, Min. Value, Selectable batch & stastical printout.
• Other optional sofrware includes SB01 (for Shear, Bending). RT01 (for Rubber, Textile), EE01 (for EE2 extensometer), TT01
   (for Torsion test).
• 20,000 load counts in 3 ranges (0-20%, 20-40%, 40-100%).
• 0.01mm Displacement resolution standard for UNITEK Machines.
• 0.1mm Displacement resolution standard for UTE Machines.
• Optional EE2 Extensomete.You will get two simultaneous graphs (Load Vs Displacement and Load Vs Extension) on PC. Proof stress,    youngs modulus calculation.
• Overload protection for full scale load. Additional Safe load entry for better protection.


Following features are applicable only for UNITEK Machines.
• 2,000 Drive rati, with precision DC Servo Motor & Drive.
• Wire connected REMOTE for easy Loading/Unloading of specimens.
• Limit switch protection on both sides of Cross Head Travel.
• Watch dog safety to avoid malfunction.

Notes :
• With EE2 extensometer, EE2 hardware & EE01 software is necessary.
• There will be only power on switch & LED on external panel, All machine connections will be from  this external panel.
• There will be only serial cable connection from panel to PC.
• For UTE Machines Control Valve & Release Value operation is manual.
• PC & its accessories are not in standard of supply.

SPECIFICATION :

 MODEL NO.  UNITEK
 9501		  UNITEK 9505  UNITEK 9510  UNITEK
 9550		  UNITEK 95100  UNITS
 250  500
 Load Range  0-1  0-5  0-10  0-50  0-100  kN
 Load  Selection  1st Range
 0-20% of  F.S.		  1/20000
 of F.S. 		 1/20000
 of F.S. 		 1/20000
 of F.S. 		 1/20000
 of F.S. 		 1/20000
 of F.S. 		 -
 1st Range
 20-40% of  F.S.		  1/10000
 of F.S. 		 1/10000
 of F.S. 		 1/10000
 of F.S. 		 1/10000
 of F.S. 		 1/10000
 of F.S. 		 -
 1st Range
 40-100% of  F.S.		  1/4000
 of F.S. 		 1/4000
 of F.S. 		 1/4000
 of F.S. 		 1/4000
 of F.S. 		 1/4000
 of F.S. 		 -
 Load measuring accuracy  +% from 2% to  100% of load cell  used.  +% from 2% to  100% of load  cell used.  +% from 2% to  100% of load cell  used.  +% from 2% to  100% of load cell  used.  +% from 2%
 to 100% of
 load cell
 used.		  -
 Max. Crosshead stroke  1000
 ( Without grips &  load cell ) 		 1000
 ( Without grips  & load cell )		  1000
 ( Without grips &  load cell )		  1000
 ( Without grips &  load cell )		  1000
 ( Without
 grips & load cell )		  -
 Clearance between  columns  450  450  450  450  450  mm
 Crosshead displacement  measurement  0.01  0.01  0.01  0.01  0.01  mm
 Crosshead speed range  0.5-500  0.5-500  0.5-500  0.5-500  0.25-250  0.5-500  mm/min
 Power Supply  230 VAC, 50 Hz  Single phase  230 VAC, 50 Hz  Single phase  230 VAC,
 50 Hz Single  phase 		 230 VAC,
 50 Hz Single phase 		 230 VAC, 50 Hz Single  phase  -

MAIN SCREEN GRAPH WITH EE2 EXTENSOMETER REAL TIME PRAPH ON PC
REAL TIME GRAPHS WITH EE2 EXTENSOMETER GRAPHS COMPARISION & POINT TRACING STATISTICS & BATCH RESULT
